sensor

1/3” 960P Megapixel CMOS AHD

Effective Pixels

960P 1.3 Megapixel

Signal system

                                                        PAL/NTSC

Horizontal resolution

960P

minimum illumination

                                                    0lux/F1.2 (LED ON)

Audio

Without Audio

lens

F=2.1mm/2.8mm/3.6mm

SNR

≥50dB

Shutter speed

PAL:1/50 s -1/100.000 s,  NTSC : 1/60s – 1/100.000 s

W/B

ATW

IR wavelength

850nm

IR light

No

Distance

10m-15m

Video output

1Vp-p,75 ohm, BNC

Power supply

DC 12V ± 10%

Working temperature

-10℃~+50℃

Waterproof grade

IP66

Dimension

50mm x 44mm x 32mm

Weight

0.35Kgs
