Features at a glance
PRODUCT SPECIFICATIONS
| PARAMETER | 4CH 720P Dual SD Card MDVR | Language | English |
| Operation System | Linux | Interface | Imaging menu operation interface (OSD Menu) |
| Password Security | Two levels authority: admin, user | Video Input | 4CH 720P 960P AHD Camera |
| Video Output | 1 composite video & 1 VGA outputs | Video standard | PAL, NTSC |
| Video compression | H.264 Main profile, 100 frame / sec | Video Display | Single/Quad screen video |
| Audio Input | 4 audio input | Audio Output | 1 audio output |
| Audio Code |
G726
|
Way of recording | Simultaneous AV recording |
| Image format | CIF/HD1/D1/720p optional | Standard of Video Stream | ISO14496-10 |
| Audio Code Rate |
40KB/s
|
Data Storage | Support 2x 256GB SD storage |
| Alarm input | 8x Alarm input | Alarm output | 2x Alarm output, with 12V high electrical level |
| RS232 port | 2x RS232 | RS485 port | 2x RS485 |
| RJ45 Port | 1x 10M/100M auto adjust Ethernet port | Intercom | support |
| Speed pulse |
External connect
|
Others | LED panel |
| 3G WCDMA | optional | 4G LTE | Optional, support TD-LTE/FDD-LTE |
| WIFI | Optional, 802.11b/g/n | GPS |
Optional, embedded module, show Geo-location, speed etc. Wireless upload function (Optional)
|
| G-sensor |
Built-in
|
PRODUCT CONFIGURATION
