Mini 720p 4ch Dual SD Card 2*128GB Car Black Box Linkage Alarm

Model
EMV-SD1101CE
MOQ
1
Payment
T/T
Certification
CE,FCC,ROSH,Emark
Channel
4CH

Product Categories

Product Information

Features

Product Name EMV-SD1101CE
Parameters 4CH/720p/Real-time HD Recording/Support 2*128GB SD Card/H.264/H.265 Video Compression/Built-in GPS/Built-in G-sensor

/Built-in 4G/4 Ways Video Input/4 Ways Audio Input/Dc 8v~36v/3CH Alarm Input/1CH Alarm Output

Main Functions 4CH 720p AHD MDVR

H.264/H.265 compression
4ch video & 4ch audio input
Real-time HD video recording,720p/D1/HD1/CIF for optional
Frame adjustable
8v~36v working voltage,translent voltages on 6v~70v,suitable for all kinds of vehicles
Max support 2*128GB SD card(support dual SD card)
Exclusive file system
3CH alarm input,linkage of multiple alarms,1CH alarm output
Support SMS remote configuration
Support phone calling
Support OTA function for convenient maintenance
Support PTZ control,LED advertisement
Support the GPS,3G/4G module,Wifi(for optional)
Service OEM/ODM Private Label LOGO or Packaging Customized
Certifications EC-RED Certification/CE/FCC/E Mark/IP69K
Shipment By Air,By Sea or Express
Payment Terms Alibaba trade assurance,western union,T/T



                                        Server overview

The server mainly includes six parts: user server, gateway server, streaming media server, database server, storage server and web server.

Database server:mainly used to store server configuration information, alarm events, etc.

Login server: accept the registration of various servers, and coordinate and manage the successfully registered servers. The system allocates the user management server for the client and configuration side, and the gateway server for the vehicle DVR equipment, and realizes the load balance of the user management server, gateway server and other servers.

Gateway server: provide vehicle access service. The vehicle establishes a communication link with the gateway server, and transmits the vehicle position and status information through this link.

Streaming media server: provides media data forwarding function. It mainly includes audio and video, intercom, monitoring,capture, parameter configuration, search and download for data forwarding.

User management server: provide client access service. WiFi automatic download server: after the train enters the station, it will automatically connect and download the video files if there is WiFi.

Storage server: used to store pictures captured by video recording.

Web server: mainly provides GIS electronic map information, and provides link service for the login of CMS background and foreground management system.

Client: provide real-time video preview, GPS positioning, electronic map display, vehicle status monitoring, picture capture,video search, video download and playback, vehicle trajectory playback, real-time alarm information monitoring, alarm information statistics, vehicle parameter configuration and other functions.

                                                        What is Vehicle Truck Guard?

Eaglemdvrvideo Intelligent vehicle Management system is the world’s leading vehicle truck video surveillance platform.At present, some problems such as cargo is missing without evidence that appear in the logistics enterprises have caused close attention of the society and the media reporters.Company can not effectively monitor the operation status of the vehicles and the drivers work because the cargo vehicles are out.With 3G/4G wireless monitoring system, managers and drivers can know the geographical location and operating status of vehicles in real time through the network ,which provide customers with better and more convenient services and enhance the competitiveness of logistics enterprises.

                                                Overview of client interface

1:Menu bar,toolbar.It is arranged vertically on the left, where the related menus of monitoring,playback,report query, user,vehicle management and server settings are located.
2:Custom logo display area.
3:User information display area.You can query the device that is currently in trouble,download the video/picture uploaded by the device,and modify the user’s password
4:The main information display area,where all relevant data will be displayed

View vehicle positioning

In the real-time monitoring interface, check the vehicle in the equipment list on the left,and the location of the vehicle will be displayed on the map.Click the+on the left side of the vehicle to expand the video channel information of the vehicle.Double click the channel where you want to play the video to start playing the video of the channel.

Device list icon status display:gray —device not online; gree —device online, normal function;purple —device online,GPS not positioning;red —device online,alarm.

Real time alarm

In the real-time monitoring interface,if the device generates an alarm(overspeed,fatigue driving,etc),the alarm indicator at the bottom of the map will turn off from the normal status to light up.Click to view the alarm content.

App Terminal Remote Control

1.Support mobile terminal network login.

2.Support online viewing video.

3.Support online control of video recording.

4.Support native video playback.

5.Support video download and replay.

6.Support for iOS and Android.

Item Parameter
OS Linux
Language Chinese/English/Others (can be customized)
Video Compression H.264/H.265 Compression Mode
OSD Overlays information such as date time and vehicle ID
Graphical User
Interface
Can connect to external LED screen. Setup system parameters with the remote
control.
Video Input 4CH 720P AHD/ 4CH standard definition /2CH high definition+2CH standard
definition mixed video input ,aviation plug.
Video Output
1CH CVBS+ VGA output for optional, 1.0Vp-p, 75Ù, aviation plug.
Preview
Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full
screen preview
Resolution 720P/D1/HD1/CIF, MAX:4 channels of 720P
Video Standard PAL: 100f/s , CCIR625 line,50field;
NTSC: 120f/s, CCIR525 line,60field;
CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional;
HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional;
D1: 800Kbps ~ 3Mbps, 8 level video quality optional;
720P: 4Mbps-6Mbps, 8 levels video quality optional
Record Mode The default setting is auto recording after power on. Timed recording, alarm
trigger recording and manual recording are supported.
Audio Input 4CH ,Aviation Plug
Audio Output 2CH,Front port is earphone port ,rear port connects to BNC connector. The
output level: 1V – 2V
Compression  G.726 compression, 8KB/s speed
Alarm Input 4CH IO Alarm Input, 1CH AD input, pulse speed input; Support alarm linkage
function
Alarm Output 2CH Relay Alarm Output, Support the linkage acousto-optic alarm, cut off fuel
oil/power,etc
Communication Interface 1CH RS232, support extension device, such as POS machine, Oil Feul sensor, LED
advertising screen , etc.
Wireless transfer Support Built-in 3G/4G network, WCDMA,CDMA2000,TDD-LTE,FDD-LTE…
Support Built-in/External WIFI,Compatible with GPRS,EDGE
Position Support Built GPS/BD Module,can make playback analysis of vehicle routing
G-Sensor Support G-sensor
Storage 2pieces SD Card,each max 2*256GB SD Card, mirror recording to protect data
from loss
Upgrade Support USB flash disk updating,SD card upgrade , OTA remote upgrade
automatically
File Format H.264/H.265 General video format
USB Front panel supports USB port, support USB flash disk upgrade to backup; hard
disk box USB port, can back up video data
Video Search Search video by Record Time/Record Type etc
Playback Max support 4CH Replay /Stop/Fast Forward/Fast Reverse at same time
Safety Management User/Admin 2 Levels Different Passwords , support screen lock
Serial Port
Extension
Support kinds of Access Equipment such as LED Advertising, PTZ control, Oil Fuel
Sensor,etc.
Power
Management
Adaptive wide power input, support Wide Voltage, Over-load、Over-voltage、
Short Circuit、Reverse Protection..Support Time Setting/Delay power off
Voltage Input DC:+8V ~ +36V
Voltage Output +12V@4A
Power-off
Protection
UPS Technology,All video information can be saved automatically when the
power is cut off, and make sure that all the files can not be damaged.
Power
Consumption
Normal Working <5W Stand-by Status <0.5W
Temperature -30℃ to +75℃
Humidity 20% to 80%
Size 140(W) x42(H) x142(D) mm
Net Weight 600g

                                                         Accessories List

*Mobile Digital Recorder

*6-pin Power Cable

*Video Audio Output Cable

*24-pin Trigger And EIA/TIA 485/322 Cable

*GPS Antenna

*4G Antenna* USB Big Head Line(Five With One)

*Installation CD

*MDVR Security Key* Hard Disk Sticker

*MDVR Remote Control

*User Manual

Packing & Shipping

We support both OEM & ODM packaging. Our normally delivery method are by the sea, by air, by international express (DHL, UPS, TNT, FedEx)
