Product Feature
PC,Smart Phone,E-mail/FTP receiving alarm information
MP Lens
H.264 Compression type
IP68,Outdoor Side view Camera
Motion Detection
Can work with mdvr hikvision ,Dahua, ICar Vision, Streamax MDVR/MNVR,all brands MNVR
Feature:
● Outdoor IR IP Vehicle Heavy-Duty Camera
● 2.0 Mega Pixel1080P ,1920X1080P
● Video Compression: H.264 Main Profile; AVI Baseline
● Main Stream: HD 1920*1080P 1-20fps
● H.264 Compression Plug & Play,P2P Support Mobile Remote Viewing
● 12pcs IR LED, IR distance: 10m-15m
● Audio:With Audio(without Audio optional)
● Waterproof:IP67
● Support RTSP of Main Stream/Sub Stream
● Megapixel Lens: 2.8mm/3.6mm /6mm/8mm
● Support RTSP Compatible with AVI Media Player
● Smart Phone Support: iPhone, iPad, Android
Product Specification
| Model | 1080P IP Inside View Camera | |
| Signal System | Progressive image scan | |
| Scanning System | 16:9 Progressive | |
| Image Sensor | 1/2.8″,2-Megapixels CMOS | |
| Sync. System | Internal | |
| Effective Pixels No. | 1920(H) x1080(W), 1280(H) x720(W) | |
| Video Output Level | 1.0Vp-p (BNC 75Ω composite) | |
| Lens | Megapixel fixed Lens 2.8mm/3.6mm | |
| IR LED & Visible Range | IR LED 12pcs (850nm), Max.8-10m | |
| Day & Night System | Mechanical ICR | |
| Min. Illumination | 0.5Lux(Color) / 0 Lux IR On | |
| Brightness | Auto/Manual | |
| Contrast | Auto/Manual | |
| Mirror | Yes | |
| Heatbeat Message | Yes | |
| Compression | H.264 | |
| Frame Rate | 1920×1080 1-20fps,1280×720 1-25fps | |
| Resolution | 1920×1080, 1280×720 | |
| Code Stream | 128Kbps~8Mbps, VBR/CBR | |
| Audio | N/A | |
| Protocol | HTTP, TCP/IP, UDP, SMTP, DDNS, DNS, SNTP, DHCP, FTP, RTP, RTSP, UPNP, ONVIF | |
| DDNS | Yes | |
| LAN Interface | Ethernet 10/100 base-T, RJ45 x1 | |
| Support P.o.E. | POE: 802.3a/f , Transmission distance <100m (Optional) | |
| WIFI (802.11b/g/n) | No | |
| User Access Setup | Yes | |
| After Event Process | Upload JPEG via FTP, Email or specified alarm center | |
| Standard Access | Support all brands MNVR, NVR | |
| Motion Detection | Yes, Support Multiple Setting Areas | |
| Browser | Internet Explorer 6.0 or Above | |
| System Upgrade | Yes, Firmware upgrade | |
| PTZ Control | Not Applicable for Fixed Cameras | |
| Power | DC12V/ 48V ,POE:802.3a/f((please confirm the power of MNVR out put to IPC) | |
| Dimension | 95mm(L)x95mm(W)x63mm(H) | |
| Weight | 0.35kgs | |
| IP Rating | IP67 |
