Feature:
Chip: Sony 600TVL
Pixels: PAL=752*582Pixels NTSC=768*494Pixels
Resolution: 600 TV Line
Illumination: 0.1-0.5Lux
Angle: 170°
Standard: NTSC/PAL
Waterproof grade: IP68
Power: DC12V
Connector:AV or 4PIN
Applicable to variety of vehicles: car, truck, RV, etc. Snap-in design, it is easy to install. Its simple and modest design and small size won't draw any attention. It helps to avoid incidents and accidents abrasion well.
Product Specification
|
TV system |
NTSC/PAL |
|
Horizontal Resolution |
600 TV lines |
|
Effective Pixels |
PAL=752*582Pixels NTSC=768*494Pixels |
|
Minimum Illumination |
0.5 Lux |
|
Lens |
1.7mm |
|
View Angle |
170 degree |
|
Sync. System |
internal |
|
S/N Ratio |
>48dB |
|
Electronic Shutter |
1/50 to 1/100,000 seconds, 1/60 to 1/100,000 seconds |
|
Video Output |
1.0Vpp, 75Ohm |
|
White Balance |
Auto |
|
Power |
DC 12V |
|
Current Consumption |
90mA |
|
Operating Temperature |
-20 to + 70°C, 95% RH maximum |
|
Storage Temperature |
-40 to + 100°C, 95% RH maximum |
|
Water-proof |
IP68 |
|
Image Reverse |
Left-right mirror |
Packing & Shipping
We support both OEM & ODM packaging. Our normally delivery method are by the sea, by air, by international express (DHL, UPS, TNT, FedEx)
Certificate
